7317 Model F3L
Dimensions w/o Media with Media
Height 746 mm 29.4 in. 823 mm 32.4 in.
Width 440 mm 17.3 in. 440 mm 17.3 in.
Depth with device
handles
289 mm 11.4 in. 289 mm 11.4 in.
Weight w/o Media with Media
Minimum 45.5 kg 100 lbs. 50 kg 110 lbs.
Maximum 72.6 kg 160 lbs. 72.6 kg 160 lbs.
Electrical
Power source loading
(typical in kVA)
N/A
Voltage range (V dc) -40 to -65
Thermal output
(typical)
770 Btu/hr
Thermal output
(maximum)
1100 Btu/hr
Power requirements
(typical)
225 watts
Power requirements
(maximum)
322 watts
Maximum altitude
(operating)
0 to 2133 m (0 to 7000 ft.)
Temperature
Requirements
Class C
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125°F)
Humidity
(Noncondensing)
Operating Non-Operating
with tape 8 to 80%
without tape 20 to 80%
Wet Bulb
Requirements
28°C (82°F)
Noise Emissions¹ Operating Idle
L
WAd
6.0 bels 6.0 bels
L
pAm
N/A N/A dBA
<L
pA
>
m
47 dBA 47 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 150mm(6 in) 0 0 0
Service³ 500mm(20 in) 0 0 0
Footprint
2
Width
440mm(17.3 in)
Depth
440mm(17.3 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. All service is performed at the front of the machine.
212 Site and Hardware Planning Information
