7012 POWERstation and POWERserver 34H, 355, 360, 365, 370, and
375
Dimensions Desktop Deskside
Height 162 mm 6.4 in. 466 mm 18.3 in.
Width (at pedestal 456 mm 18.0 in. 241 mm 9.5 in.
for deskside)
Depth 523 mm 20.6 in. 523 mm 20.6 in.
Weight
Minimum 12.7 kg 28 lbs. 12.7 kg 28 lbs.
Maximum 15.4 kg 34 lbs. 15.4 kg 34 lbs.
Electrical
Power source loading 0.29
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
585 Btu/hr
Power requirements
(typical)
185 watts
Power factor 0.5 to 0.7
Inrush current 49 amps at 120 V ac, 98 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.7 bels 5.5 bels
L
pAm
45 dBA 45 dBA(desktop)
N/A N/A (deskside)
<L
pA
>
m
41 dBA 41 dBA (desktop)
38 dBA 38 dBA(deskside)
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 760 mm(30 in) N/A N/A N/A
Footprint
2
Width Depth
Desktop 456 mm(18 in) 830 mm(33 in)
Deskside 241 mm(9.5 in) 828 mm(32.6 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
18 Site and Hardware Planning Information
