Total System Power Consumption
The following tables contain minimum and maximum power consumption for the 1.1 GHz, 1.3 GHz, 1.5
GHz, and 1.7 GHz Eserver pSeries 690. Minimum power consumption is based on a configuration
consisting of a single 4 GB memory card, 1 PCI card per I/O subsystem, and 1 DASD device per I/O
subsystem.
Maximum power consumption is based on a configurations consisting of two 32 GB memory cards per
MCM module in 1.1 GHz and 1.3 GHz machines and two 64 GB memory cards per MCM module in 1.5
GHz and 1.7 GHz machines, maximum PCI cards (20 per I/O drawer), and maximum DASD (16 per I/O
drawer).
Power consumption calculations are estimates. Actual values may vary.
Calculate heat load (Btu per hour) by multiplying the power (in watts) for the configuration by a factor of
3.4.
Note: Certain system configurations only support a maximum number of I/O drawers. If a system does not
support a particular count of I/O drawers, it is indicated with ″N/A″.
Number of I/O
Drawers
(7040-61D)
1.1 GHz 8-way Modules (minimum power
consumption, in watts)
1.1 GHz 8-way Modules (maximum power
consumption, in watts)
8-way 16-way 24-way 32-way 8-way 16-way 24-way 32-way
1 1911 2867 3823 4779 3042 4586 6130 7674
2 2279 3235 4191 5147 4090 5634 7178 8722
3 N/A 3603 4559 5515 N/A 6682 8226 9770
4 N/A 3971 4927 5883 N/A 7730 9274 10818
5 N/A N/A 5295 6251 N/A N/A 10322 11866
6 N/A N/A 5663 6619 N/A N/A 11370 12914
7 N/A N/A N/A 6987 N/A N/A N/A 13962
8 N/A N/A N/A 7355 N/A N/A N/A 15010
Number of I/O Drawers
(7040-61D)
1.3 GHz 4-way Modules (minimum
power consumption, in watts)
1.3 GHz 4-way Modules (maximum
power consumption, in watts)
8-way 16-way 8-way 16-way
1 3213 5471 4932 8366
2 3581 5839 5980 9414
3 3949 6207 7028 10462
4 4317 6575 8076 11510
5 N/A 6943 N/A 12558
6 N/A 7311 N/A 13606
7 N/A 7679 N/A 14654
8 N/A 8047 N/A 15702
Chapter 2. Physical Characteristics of Systems 177
