7025 Deskside F30 Series
Dimensions
Height 620 mm 24.3 in.
Width 245 mm 9.6 in.
Width with Pedestal 350 mm 13.7 in.
Depth 695 mm 27.3 in.
Depth with Pedestal 745 mm 29.3 in.
Weight
Minimum
configuration
30 kg 65 lbs.
Maximum
configuration
50 kg 110 lbs.
Electrical
Power source loading 0.56
(maximum in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(maximum)
1535 Btu/hr
Power requirements
(maximum)
450 watts
Power factor 0.8
Inrush current³ 30 amps at 120 V ac, 60 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.8 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
41 dBA 38 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 76mm(3 in) 152mm(6 in) 51mm(2 in) 51mm(2 in)
Service Install so that it can be moved to an area providing 457mm (18 in.) on the front and 457 mm
(18 in) on the left side.
Footprint
2
Width
350mm(13.7 in)
Depth
975mm(38.4 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
Chapter 2. Physical Characteristics of Systems 63
