S70, S7A and S80 I/O Rack
Dimensions
Height 1577 mm 62.0 in.
Width 650 mm 25.5 in.
Depth 1019 mm 40.1 in.
Weight
1
(Base Rack) 159 kg 349 lbs.
Electrical (see specifications for drawers or enclosures)
Temperature
Requirements
(see specifications for drawers or enclosures)
Humidity
Requirements
(see specifications for drawers or enclosures)
Noise Emissions (see specifications for drawers or enclosures)
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service See “Service Clearances for System in an S70, S7A, or S80 I/O Rack.”
1. Configuration dependent, base weight plus weight of drawers.
Service Clearances for System in an S70, S7A, or S80 I/O Rack
The amount of space needed by the units during service is indicated by large box of the footprint. For
complete specifications, see “S70, S7A and S80 I/O Rack.”
For multiple racks placed side by side, the left and right service clearances apply only to the leftmost and
rightmost rack.
Note: If you are planning to install an S70, S7A or S80 in an RS/6000 SP System environment, see
RS/6000 SP Planning Volume 1, Hardware and Physical Environment (GA22-7280) for system
planning information.
