3514 Models 212 and 213
Dimensions
Height 610 mm 24 in
Width
Enclosure 260 mm 10.3 in
Base 345 mm 13.5 in
Depth 800 mm 31.5 in
Weight
Minimum 58 kg 128 lbs
Maximum 64 kg 140 lbs
Electrical
Power source loading .33
(typical in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
1024 Btu/hr
Power requirements
(typical)
300 watts
Power factor 0.91
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements**
Operating
16 to 32°C
(50 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Noise Emissions* Operating Idle
L
WAd
5.7 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
38 dBA 36 dBA
Impulsive noise or No No
prominent discrete
tones
Clearances Front Back Left Right
Install/Air Flow 1 mm(40 in) 50 mm(2 in) 25 mm(1 in) 25 mm(1 in)
Service Must provide reasonable service access to front and rear of unit. Recommended clearance
provides enough room to slide unit forward for access to rear.
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
**(Below 914 m (3000 ft) altitude, operating range is extended to 35°C(95°F)
Chapter 6. Physical Characteristics of the 3000 Series 245
