7329 Model 308 QIC 1/4 Tape Autoloader
Dimensions
Height 174 mm 6.8 in.
Width 224 mm 8.8 in.
Depth 578 mm 22.8 in.
Weight 15.5 kg 34 lbs.
Electrical
Power source loading
(kVA)
0.07
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
208 Btu/hr
Power requirements
(typical)
23.1 watts
Power factor 0.6
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20 to 80% 20 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions* Operating Idle
L
WAd
<5.8 bels <5.0 bels
L
pAm
54 dBA 48 dBA
Impulsive or
prominent discrete
tones
No No
* See “Noise Emission Notes” on page 336 for definitions of emissions positions.
Chapter 9. Physical Characteristics of the 7300 Series 317
