6091 Color Display Model 19i
6091 Color Display Model 19i with a maximum viewable image size of 439 mm (17.3 inches) measured
diagonally.
Dimensions
Height 485 mm 19.1 in
Width 480 mm 18.9 in
Depth 506 mm 19.9 in
Weight 34 kg 75 lbs
Electrical
Power source loading .38
(typical in kVA)
Voltage range (V ac) 100 to 120 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
480 Btu/hr
Power requirements
(typical)
185 watts
Power factor 0.7
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
1 to 60°C
(35 to 140°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80 % 8 to 80 %
Noise Emissions* Operating Idle
L
WAd
3.5 bels 3.5 bels
Clearances Front Back Left Right
Service Install so that air vents are not blocked.
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
222 Site and Hardware Planning Information
