7012 Model 397
Dimensions Desktop Deskside
Height 162 mm 6.4 in. 452 mm 17.8 in.
Width (at pedestal 442 mm 17.4 in. 241 mm 9.5 in.
for deskside)
Depth 478 mm 18.8 in. 478 mm 18.8 in.
Weight
Minimum 18.1 kg 40 lbs. 18.1 kg 40 lbs.
Maximum 21.8 kg 48 lbs. 21.8 kg 48 lbs.
Electrical
Power source loading 0.5
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
770 Btu/hr
Power requirements
(typical)
250 watts
Power factor 0.8 to 0.94
Inrush current³ 20 amps at 120 V ac, 20 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.7 bels 5.5 bels
L
pAm
46 dBA (desktop) 46 dBA (desktop)
<L
pA
>
m
48 dBA (desktop) 47 dBA (desktop)
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 760 mm(30 in) N/A N/A N/A
Footprint
2
Width Depth
Desktop 442mm(17.4 in) 782mm(30.8 in)
Deskside 241mm(9.5 in) 782mm(30.8 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
20 Site and Hardware Planning Information
