7015 System Rack R00
Dimensions
Height 1578 mm 62.0 in.
Width 650 mm 25.5 in.
Depth with Std. Door 921 mm 36.0 in.
Depth with SMP Door 1060 mm 41.8 in.
Weight
1
Base Rack 130 kg 286 lbs.
Full rack 594 kg 1309 lbs.
Electrical² (sum specified values for
drawers or enclosures in rack)
DC Rack
Power source loading
maximum in kVA³
8.4
Voltage range (V dc) -40 to -60
AC Rack
Power source loading
maximum in kVA (per
PDB)⁴
4.8
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Noise Emissions (see specifications for drawers or enclosures)
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service 915mm(36 in) 915mm(36 in) 915mm(36 in) 915mm(36 in)
Notes:
1. Configuration dependent, base rack weight plus the weight of the drawers mounted in the rack. The rack can
support up to a maximum of 13.6 kg (30) lbs/EIA (Unit).
2. The total rack power should be derived from the sum of the power used by the drawers in the rack.
Chapter 2. Physical Characteristics of Systems 41
