Eserver pSeries 690 Physical Specifications and Loads
The following tables illustrate the physical, electrical and thermal, as well as acoustical and environmental
characteristics of various Eserver pSeries 690 system configurations.
Dimensions and Weight
Physical
Characteristic
Slimline Doors Acoustical Doors
1 Frame 2 Frames 1 Frame 2 Frames
Height 2025 mm (79.72 in.) 2025 mm (79.72 in.) 2025 mm (79.72 in.) 2025 mm (79.72 in.)
Width 785 mm (30.91 in.) 1575 mm (62.00 in.) 785 mm (30.91 in.) 1575 mm (62.00 in.)
Depth 1342 mm (52.83 in.) 1342 mm (52.83 in.) 1494 mm (58.83 in.) 1494 mm (58.83 in.)
Weight (maximum
configuration)
1170 kg (2580 lbs.) 1973 kg (4349 lbs.) 1184 kg (2610 lbs.) 2000 kg (4409 lbs.)
Notes:
1. Doors are not installed during product shipment to the customer. A maximum configured system with batteries
may exceed 1134 kg (2500 lbs.).
2. When moving or relocating certain configurations of the system, the Bulk Power Regulators (BPRs) must be
removed from the top of the rack (front and rear) to ensure product stability. Specifically, removal of BPR’s from
frame A and B in the front and rear is required in systems that have a single I/O drawer, and more than 2 BPR’s
installed per BPA in the primary rack.
System Weights by Configuration
Total System Weight (Pounds)
Number of I/O
Subsystems
1 2 3 4 5 6 7 8
Slimline Doors
With IBF
2250 2415 2580 3633 3854 4019 4184 4349
Slimline Doors
Without IBF
1865 2030 2195 2418 3266 3431 3596 3761
Acoustical Doors
With IBF
2280 2445 2610 3693 3914 4079 4244 4409
Acoustical Doors
Without IBF
1923 2088 2253 2506 3326 3491 3656 3821
No Doors With IBF 2192 2357 2522 3517 3738 3903 4068 4233
No Doors Without
IBF
1807 1972 2137 2302 3150 3315 3480 3645
Note: Italicized numbers indicate single-frame systems.
Chapter 2. Physical Characteristics of Systems 171
