2103 Model H07 Fibre Channel Storage Hub
For more information on the 2103 Model H07 Fiber Channel Storage Hub see page 230.
Dimensions
Height 44 mm 1.7 in.
(1 EIA unit)
Width 219 mm 8.6 in.
Depth 367 mm 14.4 in.
Weight 4 kg 8 lbs.
Electrical
Voltage range (V ac) 100 to 240
Frequency (hertz) 50 or 60
Power requirements
(typical)
30 watts
Inrush current 1 amp at 120 Vac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
(see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Humidity
Requirements
(see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Noise Emissions (see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Clearances (see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Chapter 5. Physical Characteristics of the 2100 Series 233
