7026 Model H70 (Enterprise Server)
Dimensions
Height 350 mm 13.8 in.
8 (EIA Units)
Width 443 mm 17.4 in.
Depth 875 mm 34.2 in.
Weight
Minimum configuration 71 kg 157 lbs.
Maximum configuration 89 kg 195 lbs.
Electrical
Power source loading typical ¹ in kVA 0.46
Power source loading maximum ¹ in
kVA
0.691
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Thermal output (typical) 1485 Btu/hr
Thermal output (maximum) 2818 Btu/hr
Power requirements (typical) 434 watts
Power requirements (maximum) 650 watts
Power factor 0.9 - 0.98
Inrush current² 50 amps
Maximum altitude³ 915 m (3000 ft.)
Temperature Requirements³ Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125.6°F)
Humidity Requirements Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 27°C (80.6°F) 27°C (80.6°F)
Noise Emissions⁴ Operating Idle
L
WAd
6.2 bels 5.9 bels
L
pAm
N/A N/A
<L
pA
>
m
43 dBA 40 dBA
Impulsive or prominent discrete tones No No
Clearances Front Back Left Right
Install/Air Flow Maintenance of proper service clearances should allow proper air flow.
Service (See service clearances for the “7015 System Rack R00” on page 41)
1. The power source loading is calculated using the power factor = 0.94.
2. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
3. For altitudes above 915 meters, the maximum temperature limit is derated by 1 degree C for every 137 meters of
elevation above 915 meters.
4. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
76 Site and Hardware Planning Information
