Inovance CS200 User Manual

l Chapter 7 Selection and Dimensions
- 107 -
Table 7-8 Models and dimensions of the GTNR series cable lugs (unit: mm)
Cable Lug Model D d1 E H K B d2 F L R Crimping Tool
GTNR1.5-5 4.0 2.2 5.0 5.0 2.0 8.0 5.3 1.0 16.0 5 RYO-8
YYT-8
RYO-14
GTNR2.5-4 4.5 2.9 7.0 5.0 2.0 8.0 4.3 1.0 18.0
GTNR2.5-5 6.0 5.3 20.0 7
GTNR2.5-6 10.2 6.4 0.8
GTNR4-5 5.2 3.6 7.0 6.0 2.0 10.0 5.3 1.0 20.0
GTNR4-6 6.4
GTNR6-5 6.0 4.2 9.0 6.0 3.0 10.0 5.3 1.2 23.0
GTNR6-6 7.5 6.4 26.0
GTNR6-8 12.0 8.4 1.0
GTNR10-6 7.0 5.0 9.0 8.0 3.5 12.4 6.4 1.3 26.5
GTNR10-8 8.4 27.5
GTNR16-6 7.8 5.8 12.0 8.0 4.0 12.4 6.4 1.3 31.0 CT-38
CT-100
GTNR16-8 8.4
GTNR25-6 9.5 7.5 12.0 8.0 4.5 14.0 6.4 2.0 32.0 10
GTNR25-8 9.0 15.5 8.4 1.6 34.0
GTNR25-10 10.5 17.5 10.5 1.4 37.0
GTNR35-6 11.4 8.6 15.0 9.0 5.0 15.5 6.4 2.8 38.0
GTNR35-8 8.4
GTNR35-10 10.5 17.5 10.5 2.5 40.5
GTNR50-8 12.6 9.6 16.0 11.0 6.0 18.0 8.4 2.8 43.5 CT-100
GTNR50-10 10.5
GTNR70-8 15.0 12.0 18.0 13.0 7.0 21.0 8.4 2.8 50.0 14
GTNR70-10 10.5
GTNR70-12 13.0
GTNR95-10 17.4 13.5 20.0 13.0 9.0 25.0 10.5 3.9 55.0
GTNR95-12 13.0
GTNR120-12 19.8 15.0 22.0 14.0 10.0 28.0 13.0 4.7 60.0 16 RYC-150
GTNR120-16 16.0 17.0 64.0
GTNR150-12 21.2 16.5 26.0 16.0 11.0 30.0 13.0 4.7 60.0 24
GTNR150-16 17.0
GTNR185-16 23.5 18.5 32.0 17.0 12.0 34.0 17.0 5.0 78.0
GTNR240-16 26.5 21.5 38.0 20.0 14.0 38.0 17.0 5.5 92.0
GTNR240-20 21.0
