Chapter 3 Mechanical and Electrical Installation
- 26 -
Figure 3-7 Hoisting the CS200 (sheet metal housing)
4. Embedded mounting of the CS200 (sheet metal housing)
Figure 3-8 External hanging bracket for the CS200 (sheet metal housing)
External bracket
External bracket
