Inovance CS200 User Manual

Chapter 5 Function Code Table
- 58 -
Function
Code
Parameter Name Function Description Setting Range Default
b3.10
DI10 function
selection
29. Full-load limit input
It is the input point of the full-load limit of the
construction elevator. If the input point is inactive,
the elevator does not respond to the hall calls
during running. It is effective only in the automatic
running mode.
30: Slow-down limit input
The slow-down limit input point of the construction
elevator.
On the condition that the intelligent elevator
controller is not connected, if the input point is
inactive, the running frequency is restricted as the
value of b7.18.
On the condition that the intelligent elevator
controller is connected, if the input point is active,
the running frequency is restricted as the value of
b7.18 in the manual mode. The running frequency
is controlled by the controller in the automatic
running mode.
31. Check point input
It is the input point of the leveling encoder check of
the construction elevator. When the state changes,
the leveling encoder re-load the pulses. This
function is valid only when the intelligent elevator
controller is connected.
32. Shielding the 48# fault
If the terminal set for this function becomes ON, the
CS200 does not detect the 48# fault.
This function is used to shield the 48# fault
caused by asynchronous power-on of external
communication device and the CS200.
0
b3.14 Relay 1 function
selection
(T/A-T/B-T/C)
1. Brake control
The terminal set for this function becomes ON
when the brake release requirement in the braking
time sequence is satised. For details, see the
description of parameters in group b6.
2. Stop due to occurrence of fault
The terminal set for this function becomes ON after
a level-1 fault occurs on the AC drive.
3. Alarm due to occurrence of fault
The terminal set for this function becomes ON after
a level-2 or a level-3 fault occurs on the AC drive.
4. Fault prompt
The terminal set for this function becomes ON after
a level-4 fault occurs on the AC drive.
If the
hundred's digit
= 1, it indicates
that the
function logic
is reversed.
Unit's digit
and ten's
digit: function
selection
If they are set
to 0 and 100,
it indicates
that they are
invalid.
1
b3.15 Relay 2 function
selection
(P/A-P/B-P/C)
0
