Chapter 6 EMC
- 96 -
6.3.2 Installation of AC Reactor on Power Input Side
An AC input reactor is installed to eliminate the harmonics of the input current. As an optional device, the reactor
can be installed externally to meet strict requirements of an application environment for hormonics. The following
table lists the recommended manufacturers and models of input reactors.
Table 6-2 Recommended manufacturers and models of AC input reactors
AC Drive Model
AC Input Reactor Model
(Inovance)
Reactor Rated Current
(A)
CS200-4T18.5GB MD-ACL-50-4T-183-2% 50
CS200-4T22GB MD-ACL-80-4T-303-2% 80
CS200-4T30GB MD-ACL-80-4T-303-2% 80
CS200-4T37GB MD-ACL-80-4T-303-2% 80
CS200-4T45GB MD-ACL-120-4T-453-2% 120
CS200-4T55GB MD-ACL-120-4T-453-2% 120
CS200-4T75GB MD-ACL-200-4T-753-2% 200
6.3.3 Installation of AC Reactor on Power Output Side
Whether to install an AC output reactor on the power output side is dependent on the actual situation. The cable
connecting the AC drive and the motor should not be too long; capacitance enlarges when an over-long cable is
used and thus high-harmonics current may be easily generated.
If the length of the output cable is equal to or greater than the value in the following table, install an AC output
reactor on the power output side of the AC drive.
Table 6-3 Cable length threshold when an AC output reactor is installed
AC Drive Power
(kW)
Rated Voltage
(V)
Min. Cable Length When Selecting Output Reactor (m)
4 200 to 500 50
5.5 200 to 500 70
7.5 200 to 500 100
11 200 to 500 110
15 200 to 500 125
18.5 200 to 500 135
22 200 to 500 150
≥ 30 280 to 690 150
