Inovance CS200 User Manual

Chapter 4 Operations
- 41 -
■
Status Indicators
There are four red LED status indicators at the top of the operating panel.
Indicator Indication
RUN
OFF indicates the CS200 is in the stop state.
ON indicates the CS200 is in the running state.
LOCAL/REMOT
OFF indicates the CS200 is under the operating panel control.
ON indicates the CS200 is under the terminal control.
FLASHING indicates the CS200 is under the communication control.
FWD/REV
OFF indicates reverse motor rotation.
ON indicates forward motor rotation.
TUNE/TC
ON indicates the auto-tuning state.
■
Unit Indicators
There are three red unit indicators below the data display. These indicators operate individually or in pairs to show
the units used to display data, as shown in Figure 4-2.
Figure 4-2 Unit indicator explanation
Indicator appearance Meaning
RPM
%
A VHz
Hz for frequency
RPM
%
A VHz
A for current
RPM
%
A VHz
V for voltage
RPM
%
A VHz
RPM for rotational speed
RPM
%
A VHz
% for anything relevant
