INVT Goodrive350 Series User Manual

Goodrive350 series high-performance multi-function inverter Chapter 3
-14-
3.6.2 AC 3PH 520V (-15%)–690V (+10%) rated value
Product model
Output power
(kW)
Input current
(A)
Output
current (A)
Carrier
frequency (kHz)
GD350-022G-6
22
35
27
1–15(4)
GD350-030G-6
30
40
34
1–15(4)
GD350-037G-6
37
47
42
1–15(4)
GD350-045G-6
45
52
54
1–15(4)
GD350-055G-6
55
65
62
1–15(4)
GD350-075G-6
75
85
86
1–15(2)
GD350-090G-6
90
95
95
1–15(2)
GD350-110G-6
110
118
131
1–15(2)
GD350-132G-6
132
145
147
1–15(2)
GD350-160G-6
160
165
163
1–15(2)
GD350-185G-6
185
190
198
1–15(2)
GD350-200G-6
200
210
216
1–15(2)
GD350-220G-6
220
230
240
1–15(2)
GD350-250G-6
250
255
274
1–15(2)
GD350-280G-6
280
286
300
1–15(2)
GD350-315G-6
315
334
328
1–15(2)
GD350-350G-6
350
360
380
1–15(2)
GD350-400G-6
400
411
426
1–15(2)
GD350-500G-6
500
518
540
1–15(2)
GD350-560G-6
560
578
600
1–15(2)
GD350-630G-6
630
655
680
1–15(2)
Note:
1. The input current of 22–350kW inverter is measured in cases where the input voltage is 660V
without DC reactors and input/output reactors;
2. The input current of 400–630kW inverter is measured in cases where the input voltage is 660V
and there is input reactor;
3. Rated output current is the output current when the output voltage is 660V.
4. Within allowable input voltage range, the output current/power cannot exceed rated output
current/power.
