Goodrive350 series high-performance multi-function inverter Chapter 5
-36-
01: GD350
16:02:35
Forward
Local Ready
Set frequency
P17.00 Hz
50.00
DC bus voltage
P17.11 V
540.0
0x0000
AboutMonitoring
Menu
Digital input terminal state
P17.12
A B C
D
E
F
Fig 5.2 Main interface of LCD
Display the real-time; clock battery is not included; the time
needs to be reset when powering on the inverter
Inverter running state
display area
Display the running state of the inverter:
1. Display motor rotating direction: "Forward" – Run
forward during operation; Reverse – Run reversely during
operation; "Forbid" – Reverse running is forbidden;
2. Display inverter running command channel: "Local" –
Keypad; "Terminal" – Terminal; "Remote" - Communication
3. Display current running state of the inverter : "Ready" –
The inverter is in stop state (no fault); "Run" – The inverter is
in running state; "Jog" – The inverter is in jogging state;
"Pre-alarm" – the inverter is under pre-alarm state during
running; "Fault" – Inverter fault occurred.
Inverter station no.
and model display
area
1. Display inverter station no.: 01–99, applied in
multi-drive applications (reserved function);
2. Inverter model display: "GD350" – current inverter is
GD350 series inverter
The parameter name
and function code
monitored by the
inverter
Display the parameter name and corresponding function code
monitored by the inverter; three monitoring parameters can
be displayed simultaneously. The monitoring parameter list
can be edited by the user
Parameter value
monitored by the
inverter
Display the parameter value monitoring by the inverter, the
monitoring value will be refreshed in real time
Corresponding menu
of function key (4),
(5) and (6)
Corresponding menu of function key (4), (5) and (6). The
corresponding menu of function key (4), (5) and (6) varies
with interfaces, and the contents displayed in this area is also
different
