Goodrive350 series high-performance multi-function inverter Chapter 5
-33-
Chapter 5 Basic operation instructions
5.1 What this chapter contains
This chapter tells users how to use the inverter keypad and the commissioning procedures for
common functions of the inverter.
5.2 Keypad introduction
LCD keypad is included in the standard configuration of GD350 series inverter. Users can control the
inverter start/stop, read state data and set parameters via keypad.
Fig 5.1 Keypad diagram
Note:
1. LCD keypad is armed with real-time clock, which can run properly after power off when installed
with batteries. The clock battery (type: CR2032) should be purchased by the user separately;
2. LCD keypad support parameter-copy;
3. When extending keypad lines to install the keypad, M3 screws can be used to fix the keypad
onto the door plate, or optional keypad installation bracket can be used for this purpose.
