INVT Goodrive350 Series User Manual

Goodrive350 series high-performance multi-function inverter Appendix D
-316-
Inverter model
Recommended
cable size
(mm
2
)
Size of connectable cable (mm
2
)
Terminal
screw
specification
Tightening
torque
(Nm)
RST
UVW
PE
RST
UVW
P1, (+)
PB, (+),
(-)
PE
GD350-315G-4
95×4P
95×4P
95×4P
–
150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD350-350G-4
95×4P
95×4P
95×4P
–
150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD350-400G-4
150×4P
150×2P
95×4P
–
150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD350-500G-4
150×4P
150×2P
95×4P
–
150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
Note:
1. Cables of the sizes recommended for the main circuit can be used in scenarios where the ambient
temperature is lower than 40°C, the wiring distance is shorter than 100 m, and the current is the rated
current.
2. The terminals P1, (+), and (-) are used to connect to DC reactors and brake accessories.
D.4.2.2 AC 3PH 520V (-15%)–690V (+10%)
Inverter model
Recommended
cable size
(mm
2
)
Size of connectable cable (mm
2
)
Terminal
screw
specification
Tightening
torque
(Nm)
RST
UVW
PE
RST
UVW
P1, (+)
PB, (+),
(-)
PE
GD350-022G-6
10
10
10–16
6–16
6–10
10–16
M8
9–11
GD350-030G-6
10
10
10–16
6–16
6–10
10–16
M8
9–11
GD350-037G-6
16
16
16–25
16–25
6–10
16–25
M8
9–11
GD350-045G-6
16
16
16–25
16–35
16–25
16–25
M8
9–11
GD350-055G-6
25
16
16–25
16–35
16–25
16–25
M10
18–23
GD350-075G-6
35
16
35–50
25–50
25–50
16–50
M10
18–23
GD350-090G-6
35
16
35–50
25–50
25–50
16–50
M10
18–23
GD350-110G-6
50
25
50–95
50–95
25–95
25–95
M10
18–23
GD350-132G-6
70
35
70–95
70–95
25–95
35–95
M10
18–23
