INVT Goodrive350 Series User Manual

Goodrive350 series high-performance multi-function inverter Appendix A
-275-
A.3 Wiring
1. Ground a shielded cable as follows:
Grounding position of the
shielded cable
Grounding position of
the shielded cable
Fig A.4 Extension card grounding diagram
2. Wire an extension card as follows:
EC wiring
EC wire binding position
Fig A.5 Extension card wiring
