INVT Goodrive350 Series User Manual

Goodrive350 series high-performance multi-function inverter Chapter 5
-84-
Function
code
Name
Detailed parameter description
Default
value
P05.42
Corresponding setting of
upper limit frequency of
HDIA
-100.0%–100.0%
100.0%
P05.43
HDIA frequency input filter
time
0.000s–10.000s
0.030s
P05.44
HDIB high-speed pulse input
function selection
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIA
0
P05.45
Lower limit frequency of
HDIB
0.000 KHz – P05.47
0.000KHz
P05.46
Corresponding setting of
lower limit frequency of HDIB
-100.0%–100.0%
0.0%
P05.47
Upper limit frequency of
HDIB
P05.45 –50.000KHz
50.000KHz
P05.48
Corresponding setting of
upper limit frequency of
HDIB
-100.0%–100.0%
100.0%
P05.49
HDIB frequency input filter
time
0.000s–10.000s
0.030s
P05.50
AI1 input signal type
0–1
0: Voltage type
1: Current type
0
5.5.10 Analog output
GD350 series inverter carries one analog output terminal (0–10V/0–20mA) and one high-speed pulse
output terminal. Analog output signals can be filtered separately, and the proportional relation can be
adjusted by setting the max. value, min. value, and the percentage of their corresponding output.
Analog output signal can output motor speed, output frequency, output current, motor torque and
motor power at a certain proportion.
