Rev. 2.0
Maintenance Guide
14-4
No. Part name
19 Driver for IN, CENT, and OUT motors
20 Power supply unit
21 ATX power supply (UPS)
22 Transformer for AC power
23 Circuit breaker
24 AC input unit
25 Load cell amplifier (Optional)
26 S-LIGHT CTRL board (Option for KE-3010)
27 Feeder board
28 S-XY-relay board
29 Base IO board
30 Magnetic Scale board
31 SCM3 board (KE-3020VR Only)
32 S-VCS power supply unit (if the S-VCS is
mounted)
33 Superimpose Board
34 MOUSE/KEYBOARD Selector (Rear-side operation
(Optional))
35
Safety unit [EN specifications only]
36
Coplanarity power supply assembly
(Optional)
22
15 19
30
Figure 14-1-2-3 Right Side View
