The cable assemblies shown in the table below are to be added or deleted in EN specification.
Connect them as shown in the table.
Table 14-7-1-1
Applicable cable Connection destination
Part No. Part name Name of destination
Connector No.
Add/delete
40092574 BU LOCK SENS ASM
−−−−−
BU LOCK Add
40110058 BU LOCK SENS CABLE ASM SENSOR BLOCK2 CBL2-2 Add
40110046 SV WIRE ASM (EN)
−−−−−
EV Add
40110045 SV WIRE ASM
−−−−−
EV Delete
The cable assemblies shown in the table below are to be added in case of auto width adjustment
option.
Connect them as shown in the table.
Table 14-7-1-2
Applicable cable Connection destination
Part No. Part name Name of destination Connector No.
Add/delete
40048077
AWC MOTOR ASM
−−−−−
CN659/660 Add
40110043 AWC ENC CABLE SAM BASE I/O board BASE17 Add
40110037
(40110038)
AWC DRIVE CABLE ASM
(AWC DRIVE CABLE ASM (EN))
BASE I/O board BASE14 Add
40110039
(40110040)
AWC MOTOR CABLE ASM
(AWC MOTOR CABLE ASM (EN))
Driver
−
Add
40092577 AWC ORG SENS ASM
−−−−−
AWC ORG Add
40110061 AWC ORG SENS CABLE ASM SENSOR BLOCK2 SBL2-5 Add
40092569 BU PIN SENSOR EMISSION ASM
−−−−−
BU EMIS Add
40110053 BU PIN (EMISSION) CABLE ASM SENSOR BLOCK1 SBL1-2 Add
40092575 BU PIN SENSOR RECEIVER ASM
−−−−−
BU RCV Add
40110059 BU PIN (RECEVING) CABLE ASM SENSOR BLOCK2 SBL2-3 Add
