Kaco blueplanet 125 TL3 Operating Instruction

WARNING
Risk of burns caused by hot housing components
Housing components can become hot during operation.
› During operation, only touch the housing cover on the device.
9.2 Uninstalling the device
DANGER
Dangerous voltage due to two operating voltages
Severe injuries or death may occur if the cables and/or terminals/busbars in the device are touched. The
discharge time of the capacitors is up to 5 minutes.
› Only appropriately qualified electricians authorised by the mains supply network operator are permit-
ted to open and maintain the device.
› Before opening the device: Disconnect the AC and DC sides and wait at least 5 minutes.
↻ Device shut down and no voltage is present.
↻ AC cable disconnected AC connection [See section8.6.1}Page29].
↻ DC connection disconnected DC connection [See section8.6.2}Page29].
1 Undo the cable fittings for Ethernet cables [ W_29].
2 Undo the cable fittings for RS485 cables [ W_19].
3 Disconnect the plug from the communication circuit board.
4 Pull the interface cables out of the device.
5 Insert sealing plugs into all open cable fittings.
» The device has been uninstalled. Proceed with removal.
9.3 Disassembling the device
↻ Unit has been switched off and uninstalled.
1 Remove the screw that prevents the device from being lifted off the mount.
2 Use the lateral openings and lift the device off the mount.
» Device removed. Proceed with the packaging process.
9.4 Packaging the device
↻ Device has been uninstalled.
1 If possible, always pack the device in the original packaging. If this is no longer available, an alternative is to use equi-
valent packaging.
2 You must be able to close the box completely and it must be able to accommodate the weight and size of the device.
9.5 Storing the device
CAUTION
Property damage as a result of condensation
Faulty storage can form condensate in the device and impair the device functioning (e.g. storage outside
the ambient conditions or temporary relocation from a cold to a hot environment).
ü Store in accordance with the technical data > Environmental data [See section4.3}Page13]
› Prior to installation, check the inner area for condensation and if necessary, allow it to dry sufficiently
before installation.
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 110 TL3 KACO blueplanet 125 TL3
KACO blueplanet 137 TL3 KACO blueplanaet 150 TL3
Page 30
EN
