30/DISASSEMBLING THE ENGINE 100
18.5Removing the alternator cover
300004-10
– Remove screws . Take off the alternator cover.
– Remove dowels.
18.6Removing spacer
302124-10
– Remove the spacer  of the countershaft.
18.7Removing gear position sensor
302126-10
– Remove screws. Remove the gear position sensor .
300007-10
– Remove O-ring .
– Remove contact pin  and the contact springs .
18.8Removing oil filter
300009-10
– Remove screws. Remove the oil filter cover  with the O-ring.
– Pull the oil filter element  out of the oil filter case.
Circlip pliers reverse (51012011000) ( p. 212)
