TECHNICAL DATA - CHASSIS 179

Brake/tail light (690 Enduro USA) P21/5W / socket BAY15d 12 V

21/5 W

License plate lamp W5W / socket W2.1x9.5d 12 V

5 W

Validity Front tire Rear tire

(690 Enduro EU, 690 Enduro AUS/UK) 90/90 - 21 M/C 54H TL

Metzeler Enduro 3 Sahara

140/80 - 18 M/C 70H TL

Metzeler Enduro 3 Sahara

(690 Enduro USA) 90/90 - 21 M/C 54R TT

Pirelli MT 21 RALLYCROSS

130/90 - 18 M/C 69R TT

Pirelli MT 21 RALLYCROSS

Additional information is available in the Service section under:

http://www.ktm.com

29.2Capacity - fuel

Total fuel tank capacity,

approx.

12 l (3.2 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p. 209)

Fuel reserve, approx. 2.5 l (2.6 qt.)
