06/AIR FILTER 56
300203-10
– Remove screws .
300204-10
– Remove screws .
300205-10
– Loosen hose clip .
300206-10
– Raise the air filter box at the rear.
– Loosen the spring-loaded band-type clamp with the special tool and detach bleed
hose .
Pliers for spring-loaded band-type clamp (60029057100) ( p. 214)
– Detach connector  of the intake air temperature sensor.
– Take off the air filter box.
10.4Installing the air filter box
300206-11
– Attach connector  of the intake air temperature sensor.
– Mount bleed hose . Mount the spring-loaded band-type clamp using the special
tool.
Pliers for spring-loaded band-type clamp (60029057100) ( p. 214)
300205-11
– Position the air filter box.
– Mount and tighten hose clip .
