04/SHOCK ABSORBER, SWINGARM 36
8.8Adjusting the riding sag
– Remove the shock absorber. ( p. 36)
– After removing the shock absorber, clean it thoroughly.
201352-10
– Choose and mount a suitable spring.
Guideline
Spring rate
Soft 75 N/mm (428 lb/in)
Medium (standard) 80 N/mm (457 lb/in)
Hard 85 N/mm (485 lb/in)
Info
The spring rate is shown on the outside of the spring.
– Install the shock absorber. ( p. 37)
– Check the static sag of the shock absorber. ( p. 34)
– Adjust the rebound damping of the shock absorber. ( p. 34)
8.9Removing the shock absorber
– Raise the motorcycle with the work stand. ( p. 9)
300562-10
– Remove screws .
300563-10
– Lift the rear fairing.
– Remove screws .
300564-10
– Remove screw .
– Repeat the operation on the opposite side.
