KTM 690 ENDURO EU 2008 User Manual

TECHNICAL DATA - CHASSIS 178
Frame Lattice frame made of chrome molybdenum steel tubing,
powder-coated
Fork WP Suspension 4860 MXMA
Shock absorber WP Suspension 4618 with Pro‑Lever deflector
Suspension travel
Front 250 mm (9.84 in)
Rear 250 mm (9.84 in)
Brake system
Front Disc brake with dual-piston brake caliper, floating
Rear Disc brake with single-piston brake caliper, floating
Brake discs - diameter
Front 300 mm (11.81 in)
Rear 240 mm (9.45 in)
Brake discs - wear limit
Front 4.5 mm (0.177 in)
Rear 3.5 mm (0.138 in)
Tire air pressure, road, solo
Front 1.8 bar (26 psi)
Rear 1.8 bar (26 psi)
Tire air pressure with passenger / fully loaded
Front 2.0 bar (29 psi)
Rear 2.2 bar (32 psi)
Tire air pressure, offroad, single rider
Front 1.5 bar (22 psi)
Rear 1.5 bar (22 psi)
Secondary drive ratio 15:45
Chain 5/8 x 1/4” X‑ring
Steering head angle 63°
Wheelbase 1,498±15 mm (58.98±0.59 in)
Seat height unloaded 910 mm (35.83 in)
Ground clearance unloaded 300 mm (11.81 in)
Weight without fuel approx. 138.5 kg (305.3 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
29.1Lighting equipment
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal R10W / socket BA15s 12 V
10 W
Brake/tail light (690 Enduro EU,
690 Enduro AUS/UK)
LED
