KTM 690 ENDURO EU 2008 User Manual

TECHNICAL DATA - FORK 180
Fork part number 14.18.7D.11
Fork WP Suspension 4860 MXMA
Compression damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Spring length with preload spacer(s) 472 mm (18.58 in)
Spring rate
Soft 5.2 N/mm (29.7 lb/in)
Medium (standard) 5.4 N/mm (30.8 lb/in)
Hard 5.6 N/mm (32 lb/in)
Fork length 890 mm (35.04 in)
Air chamber length 100
+30
−10
mm (3.94
+1.18
−0.39
in)
Fork oil per fork leg 645 ml (21.81 fl. oz.) Fork oil (SAE 5) ( p. 209)
