30/ENGINE - WORK ON INDIVIDUAL PARTS 135
300128-10
– Compress the expansion ring and remove it, using suitable pliers.
– Take the freewheel out of the primary gear.
19.41Checking freewheel
300131-10
– Insert the freewheel gear in the primary gear , turning the primary gear clock-
wise; do not twist!
– Check the locking action of the freewheel gear .
» If the primary gear does not turn clockwise or if it does not lock counterclock-
wise:
– Remove the freewheel. ( p. 134)
– Turn the freewheel 180°.
– Install the freewheel. ( p. 135)
19.42Installing freewheel
300129-10
– Lubricate all parts thoroughly.
– Push the freewheel into the primary gear.
Info
Note the direction of rotation.
300128-11
– Install the expansion ring .
300130-10
– Make sure that all lugs of the expansion ring locate in the slits of the freewheel.
Info
If necessary, use a screwdriver to ease them in.
