30/DISASSEMBLING THE ENGINE 112
300011-10
– Remove screws. Remove the oil filter cover with the O-ring.
– Pull the oil filter element out of the oil filter case.
Circlip pliers reverse (51012011000) ( p. 246)
18.9Removing thermostat
300010-10
– Remove screws. Take off the thermostat case with the radiator hose.
– Pull out the thermostat .
18.10Setting engine to ignition top dead center
300023-10
– Turn the crankshaft counterclockwise until markings of the camshafts are flush
with the marks of the camshaft support plate.
300024-10
– Remove screw .
Info
Look through the hole to check that the position hole of the balancer shaft
is visible.
– Screw in special tool .
Engine blocking screw (77329010000) ( p. 253)
18.11Removing water pump wheel
300012-10
– Remove screws . Take off the water pump cover.
