30/DISASSEMBLING THE ENGINE 113
300013-10
– Remove screw . Take off the water pump wheel .
– Take off the water pump cover seal.
Info
Do not lose the centering pins.
300014-10
– Remove the shaped washer .
18.12Removing clutch cover
300015-10
– Remove screws . Take off the clutch cover.
– Take off the dowels. Remove the clutch cover seal.
18.13Removing spacer and spring
300154-10
– Remove the spacer and spring of the shift shaft.
18.14Removing spark plug
300016-10
– Remove the spark plug using the special tool .
Spark plug wrench (75029172000) ( p. 253)
