TECHNICAL DATA - ENGINE TIGHTENING TORQUES 190

Plug, oil bore for oil radiator M10x1 15 Nm (11.1 lbf ft) –

Screw, unlocking of timing chain ten-

sioner

M10x1 10 Nm (7.4 lbf ft) –

Spark plug M12x1.25 17 Nm (12.5 lbf ft) –

Coolant temperature sensor on cylinder

head

M12x1.5 12 Nm (8.9 lbf ft) –

Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –

Oil pressure regulator valve plug M12x1.5 20 Nm (14.8 lbf ft) –

Plug, oil bore M14x1.5 15 Nm (11.1 lbf ft)

Loctite

243™

Engine case stud M16x1.5 25 Nm (18.4 lbf ft)

Loctite

243™

Rotor nut M18x1.5 100 Nm (73.8 lbf ft) –

Nut, engine sprocket M20x1.5 60 Nm (44.3 lbf ft)

Loctite

243™

Nut, inner clutch hub M20x1.5 100 Nm (73.8 lbf ft)

Loctite

243™

Nut, primary gear M20LHx1.5 90 Nm (66.4 lbf ft)

Loctite

243™

Plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) –

Plug, timing chain tensioner M20x1.5 25 Nm (18.4 lbf ft) –

Plug, oil thermostat M24x1.5 15 Nm (11.1 lbf ft) –

Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –
