U20-3, U25-3 WSM Machine body (Mechanism section)
II-M-9
b. Engine mount
No.
1
2
3
4
5
6
7
8
9
10
PART NAME
Bracket (1, Engine)
Bracket (2, Engine)
Bolt
Rubber, cussionLock
Bolt
Washer, plain
Washer, spring
Nut
Bolt
Spring, plate
10 9
