U20-3, U25-3 WSM Machine body (Service section)
II-S-25
3) Travel lever assembly view
(11)(12)(13)(14)(15)(16)(17)(18)(19)
(29)(30)(31)
(35)(36)(37)
(5)
(2)
(9)(10)
(9)(10)
268(reference)
398(reference)
a
a : First orient the lock hole vertically, then insert the pin and others, and
finally tighten up the bolts (7).
(8)(7)
(6)
(3)
(3) Fitting the plastic cap (3)
Install the cap tight enough.
Otherwise the turning part may get
rusty.
(4) Tightening torque of bolt (7)
60.8~70.6N
•
m (6.2~7.2kgf
•
m)
(5) Apply grease to the needle and DU
bushing, and make sure the rotary shaft
turns smoothly.
(6) Tightening torque of link ball lock nut
39.2~45.1N
•
m (4.0~4.6kgf
•
m)
(32)(33)(34)
(28)(27)(26)(25)(24)(23)(22)(21)
(20-3)(20-2)(20)
(5)
(4)
No.
2
3
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
29
30
31
35
36
37
Part No.
RB419-6530
RB419-6531
68741-6536
68741-6543
02074-60120
RC411-6537
01176-61025
04512-60100
01175-61045
02118-60100
RB411-6532
52300-7517
04512-60100
02118-60100
02116-50100
68011-3268
52300-7519
04512-60100
02118-60100
RB411-6545
RB411-6546
08511-01615
04011-60160
05525-51600
RB411-6533
04013-60080
05525-50800
Remarks
M12 × 1.25 4T
M10 × 1.25 9T
M10 × 1.25 7T
M10 × 1.25 4T
M10 × 1.25 4T
M10 × 1.25 4T
M10 × 1.25 4T
Q’ty
1
1
2
1
1
1
2
2
4
4
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
Part name
Lever, assembly (travel, left)
Lever (travel, left)
Needle bearing
Plastic cap
Nut
Pin (travel)
Bolt
Plain washer
Bolt
Nut
Rod (10-305)
Link ball 1
Spring washer
Nut
Nut
Left-threaded lock nut
Link ball 2
Spring washer
Nut
Link, assembly (travel, left)
Link (travel, left)
Bushing
Plain washer
Snap pin
Rod (145)
Plain washer
Snap pin
No.
4
5
20
20-2
20-3
21
22
23
24
25
26
27
28
32
33
34
Part No.
RB419-6535
RB419-6536
68741-6536
02074-60120
RC601-6538
37410-4218
RP801-6556
52300-7517
04512-60100
02118-60100
02116-50100
68011-3268
52300-7519
04512-60100
02118-60100
RB411-6547
RB411-6548
08511-01615
04011-60160
05525-51600
Q’ty
1
1
2
1
1
1
1
1
1
1
2
2
1
1
1
1
1
2
1
1
Remarks
M12 × 1.25 4T
M10 × 1.25 4T
M10 × 1.25 4T
M10 × 1.25 4T
Part name
Lever, assembly (travel, right)
Lever (travel, right)
Needle bearing
Nut
Rod (10-225)
Turnbuckle
Rod (180)
Link ball 1
Spring washer
Nut
Nut
Left-threaded lock nut
Link ball 2
Spring washer
Nut
Link, assembly (travel, right)
Link (travel, right)
Bushing
Plain washer
Snap pin
