Parameter Name / value range / [default seng] Info
0x402A:004
(P805.04)
Sequencer segment 5: Digital outputs
(Segment 5: Digital outp.)
0 ... [0] ... 255
•
From version 03.00
Oponally: Set digital outputs to the level set here for the execuon
me of the segment.
Note!
In order that the control of a digital output is executed by the sequencer,
the following assignment must be made for the respecve digital out-
put:
•
Relay: 0x2634:001 (P420.01) = "Sequencer controlled [100]"
•
Digital output 1: 0x2634:002 (P420.02) = "Sequencer controlled [100]"
Bit 0 Relay 0 = X9/NO-COM open and NC-COM closed.
1 = X9/NO-COM closed and NC-COM open.
An inversion set in 0x2635:001 (P421.01)is taken into consideraon
here.
Bit 1 Digital output 1 0 = set digital output 1 to LOW level.
1 = set digital output 1 to HIGH level.
An inversion set in 0x2635:002 (P421.02) is taken into consideraon
here.
0x402A:005
(P805.05)
Sequencer segment 5: Analog outputs
(Segment 5: Analog outp.)
0.00 ... [0.00] ... 10.00 VDC
•
From version 03.00
Oponally: Set analog output to the voltage value set here for the execu-
on me of the segment.
Note!
In order that the control of the analog output is executed by the
sequencer, the following assignment must be made for the analog out-
put:
•
Analog output 1: 0x2639:002 (P440.02) = "Sequencer controlled [10]"
0x402A:006
(P805.06)
Sequencer segment 5: PID setpoint
(Segment 5: PID setp.)
-300.00 ... [0.00] ... 300.00 PID unit
•
From version 03.00
PID control value for the segment.
•
Only relevant if the PID control in 0x4020:001 (P600.01) is acvated.
0x402A:007
(P805.07)
Sequencer segment 5: Torque setpoint
(Segment 5: Torque setp.)
-400.0 ... [100.0] ... 400.0 %
•
From version 03.00
Torque setpoint for the segment.
•
Only relevant for operang mode 0x6060 (P301.00) = "MS: Torque
mode [-1]".
0x402A:008 Sequencer segment 5: NetWordOUT2
0 ... [0] ... 65535
•
From version 03.00
Oponally: Set the NetWordOUT2 data word to the value set here for
the execuon me of the segment.
•
The NetWordOUT2 data word 0x400A:002 (P591.02) can be mapped
to a network register to transfer the set value as process date.
0x402A:009 Sequencer segment 5: Reserved
0 ... [0] ... 4294967295
•
From version 03.00
0x402B:001
(P806.01)
Sequencer segment 6: Frequency setpoint
(Segment 6: Frequency setp.)
-599.0 ... [0.0] ... 599.0 Hz
•
From version 03.00
Frequency setpoint for the segment.
•
Only relevant for operang mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
•
Direcon of rotaon according to sign.
0x402B:002
(P806.02)
Sequencer segment 6: Acceleraon/deceleraon
(Segment 6: Accel./decel.)
0.0 ... [5.0] ... 3600.0 s
•
From version 03.00
Acceleraon/deceleraon for the segment.
•
Only relevant for operang mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
•
The set me refers to the acceleraon from standsll to the set maxi-
mum frequency. The deceleraon is eected with the same ramp.
0x402B:003
(P806.03)
Sequencer segment 6: Time
(Segment 6: Time)
0.0 ... [0.0] ... 100000.0 s
•
From version 03.00
Runme for the segment aer the expiry of which it is switched over to
the next step of the sequence.
•
Only relevant for Sequencer mode 0x4025 (P800.00) = "Time opera-
on [1]" or "Time & step operaon [3]".
•
With the seng "0.0", the segment will be skipped.
Sequencer
Segment conguraon
332
