Lenze I51AE175B User Manual

Parameter Name / value range / [default seng] Info
0x2631:002
(P400.02)
Funcon list: Run
(Funcon list: Run)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Run" funcon.
Funcon 1: Start / stop motor (default seng)
Funcon 1 is acve if no further start commands (start forward/start
reverse) have been connected to triggers, no keypad control is acve and
no network control is acve.
Trigger = TRUE: Let motor rotate forward (CW).
Trigger = FALSE: Stop motor.
Notes to funcon 1:
•
If "Enable inverter" 0x2631:001 (P400.01) is set = "Constant TRUE [1]",
the only permissible trigger for this funcon is a digital input in order
that the motor can be stopped again any me.
•
The stop method can be selected in 0x2838:003 (P203.03).
•
The funcon also serves to realise an automac start aer switch-on.
4Starng performance ^ 103
Funcon 2: Start enable/stop motor
Funcon 2 is acve if further start commands have been connected to
triggers, keypad control is acve or network control is acve.
Trigger = TRUE: Start commands of the acve control source are ena-
bled.
Trigger = FALSE: Stop motor.
Notes to funcon 2:
•
If no separate start enable is required for the applicaon, the trigger
"Constant TRUE [1]" must be set.
•
The stop method can be selected in 0x2838:003 (P203.03).
Assignment of a trigger for the "Run" funcon.
Trigger = FALSE-TRUE edge: Drive is started in forward rotang direcon
(CW) if the following condions are fullled:
•
Controller is enabled and no error or quick stop are acve.
•
No other start command is congured (start-forwards/start-back-
wards/run-forwards/run-backwards = "Not connected [0]").
Trigger = TRUE-FALSE edge: drive is stopped again.
11 Digital input 1
0x2631:003
(P400.03)
Funcon list: Acvate quick stop
(Funcon list: Quick stop)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate quick stop" funcon.
Trigger = TRUE: Acvate quick stop.
Trigger = FALSE: Deacvate quick stop.
Notes:
•
The "Quick stop" funcon brings the motor to a standsll within the
deceleraon me set in 0x291C (P225.00).
0 Not connected
0x2631:006
(P400.06)
Funcon list: Start forward (CW)
(Funcon list: Start forward)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Start forward (CW)" funcon.
Trigger = FALSE↗TRUE (edge): Let motor rotate forward.
Trigger = TRUE↘FALSE (edge): No acon.
Notes:
•
In order to start the motor, "Enable inverter" 0x2631:001 (P400.01)
and "Run" 0x2631:002 (P400.02) must be set to TRUE.
•
Aer the start, the motor runs unl "Run" is set to FALSE, another
stop command is given or the inverter is disabled.
• In the case of a bipolar setpoint selecon (e.g ±10 V), the funcon is
executed irrespecve of the rotang direcon. The rotang direcon
is determined by the sign of the setpoint.
0 Not connected
0x2631:007
(P400.07)
Funcon list: Start reverse (CCW)
(Funcon list: Start reverse)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Start reverse (CCW)" funcon
Trigger = FALSE↗TRUE (edge): Let motor rotate backward.
Trigger = TRUE↘FALSE (edge): No acon.
Notes:
•
In order to start the motor, "Enable inverter" 0x2631:001 (P400.01)
and "Run" 0x2631:002 (P400.02) must be set to TRUE.
•
Aer the start, the motor runs unl "Run" is set to FALSE, another
stop command is given or the inverter is disabled.
• In the case of a bipolar setpoint selecon (e.g ±10 V), the funcon is
executed irrespecve of the rotang direcon. The rotang direcon
is determined by the sign of the setpoint.
0 Not connected
Flexible I/O conguraon
Start / stop motor
353
