6.6 Installing/removing the supporting box
Operating Manual GMK6300L 3 112 xxx en 6 - 65
xx.xx.xxxx
6.6 Installing/removing the supporting box
The rear support mechanism comes from the rear supporting box. When
using additional equipment, this can be completely removed with support-
ing cylinders and outrigger beams for driving on roads.
Auxiliary equipment required
– Appropriate lifting gear (chain or rope suspension gear) of sufficient
lifting capacity and guide ropes,
– A separate vehicle of sufficient load bearing capacity with a sufficient
loading area.
Dimensions and weights of removable parts;
à Dimensions and weights of removable parts, p. 1 - 10.
G
Risk of overturning when slewing the superstructure!
Support the truck crane with an outrigger span of 7.98 x 8.50/1.00 m
(26.1 x 27.9/3.3 ft) and set the corresponding RCL code before slewing the
superstructure.
Never override the RCL when slewing is switched off;
à Crane movements
during installation and removal
, p. 6 - 81.
