Operating elements for crane operation
9.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 9 - 61
xx.xx.xxxx
Outriggers
submenu
Carrier ignition display
Display for engine for driving on/off
Start engine for driving
–Red: Ignition off – engine start not possible
– Green: Ignition on – engine start possible
à p. 12 - 23
1Red: Engine off
2Green: Engine on
à p. 12 - 23
1 Starting the
engine:
Press button once
2 Engine running: Button has function
Pre-select all supporting cylinders
Switch off the
engine:
Switch off the carrier ignition
à p. 12 - 23
