MIMAKI JV5 Series Operating Manual

7-10
Error Messages
When an error message is displayed, eliminate the error according to the chart below.
If the same error message appears again, contact your distributor or our service office.
Error messages Cause Solution
An error occurred in the circuit board system.
(ROM)
Turn OFF the power to the machine and turn it
ON again after a while.
If the same error message appears again,
contact our service office or the distributor in your
region.
An error occurred in the circuit board system.
(RAM)
An error occurred in the circuit board system.
(Power supply voltage +5 V)
An error occurred in the circuit board system.
(Power supply voltage +24 V)
An error occurred in the circuit board system.
(Power supply voltage +42 V)
An error occurred in the circuit board system.
(Parameter ROM)
An error occurred in the circuit board system.
(SDRAM)
A connection error in the heads was detected.
(Abnormal temperature was detected.)
A connection error in the heads was detected.
(Abnormal voltage was detected.)
An error occurred in detecting the linear
encoder.
(Unable to count)
An error occurred in detecting the linear
encoder.
(Error in the mounting direction)
An error occurred in detecting the linear
encoder.
(Read-out count error)
An error occurred in the circuit board system.
(FPGA PDC)
An error occurred in the circuit board system.
(FPGA HDC)
The machine received some data other than
command data.
According to the application, switch the settings
for COMMON SETUP>RECEIVED DATA.
(P.5-2)
Securely connect the interface cable in position.
Use an interface cable conforming to the
specifications.
Any parameter outside the range of acceptable
numeric values was received.
Turn OFF the power to the machine and turn it
ON again after a while.
If the same error message appears again,
contact our service office or the distributor in your
region.
***** ERROR 01 *****
MA I N ROM
***** ERROR 02 *****
MA I N RAM
***** ERROR 03 *****
POWER + 5 V
***** ERROR 03 *****
POWER + 2 4 V
***** ERROR 03 *****
POWER + 4 2 V
***** ERROR 04 *****
F-ROM
***** ERROR 06 *****
SD - RAM
***** ERROR 07 *****
HEAD (----)
***** ERROR 07 *****
VOLTAGE (----)
***** ERROR 08 *****
L i n e a r ENCODER : SENSOR
***** ERROR 08 *****
L i nea rENCODER:DIR.
***** ERROR 08 *****
L i nea rENCODER:COUNT
***** ERROR 09 *****
FPGA ERROR
***** ERROR 09 *****
HDC ERROR (----)
***** ERROR 10 *****
COMMAND ERROR
**** ERROR 10-C ****
COMMAND ERROR
***** ERROR 11 *****
PARAMETER ERROR
**** ERROR 11-C ****
PARAMETER ERROR
