1-12
Connecting Cables
Connecting USB2.0 Interface Cable
Connect the PC and this machine with the USB2.0 interface
cable.
Notes on USB 2.0 Interface
z When two or more CJV30 machines are connected to one personal computer
Set the different "MACHINE NAME" for each connected CJV30. ( P.5-12)
When two or more CJV30 machines are connected to one personal computer, the personal computer may not
recognize all the CJV30 machines normally.
Reconnect the unrecognized CJV30 machine to another USB port, if available, and check to see if it is
recognized. If the CJV30 machine is not recognized by the newly connected USB port, use USB 2.0 repeater
cables available on the market.
z Notes on peripheral devices in USB high speed mode
When a peripheral device (USB memory or USB HDD) to be operated in USB high speed mode is connected to
the same personal computer that a CJV30 machine is connected to, the USB device may not be recognized.
When CJV30 is connected to the personal computer to which an external HDD is connected via USB, the speed
of data output to CJV30 may drop. That can cause the head unit to stop temporarily at the right or left end during
printing.
• Your application must be compatible with USB
2.0.
• Contact a RIP maker near your location or our
office when the USB2.0 interface is not
attached to the PC.
• Your application must be compatible with USB 2.0.
USB cable
USB2.0 repeater cable
To Next Page
