2-24
Notes When Using Medium Holder
Setting position of the medium
Set the medium so that the right end of the medium will be inside the area shown below.
The End of the Medium Should Not Exceed the Slit Line on the Platen
• If the medium is set with its end exceeding the slit line on the platen, the medium may be lifted when it is
fed obliquely. This may cause damage to the head.
Set the medium so that the right end of the medium will be inside
the area shown by an arrow. (up to the 3rd grid roller from the right
end in front of the main body)
Medium
Medium holder
Slit line
To Next Page
