MIMAKI JV5 Series Operating Manual

1-14
Inserting Ink Cartridges
Insert ink cartridges.
1
Shake the ink cartridge as shown on the right.
2
Insert the ink cartridge.
• Insert the ink cartridge lengthwise with the surface having IC
chips pointing to the left side.
• Colors are displayed on the display as follows.
Black: K, Cyan: C, Magenta: M, Yellow: Y, Light cyan: c, Light
magenta: m
Changing an Ink Cartridge
Perform as follows when [INK END] or [NEAR END] is displayed on the display.
z When [INK END] is displayed
(1)Pull out the ink cartridge to be replaced.
(2)Insert a new ink cartridge, paying attention to the direction of IC chip.
z When [NEAR END] is displayed
There is a little ink left. Though printing can be continued even if it is displayed, it is recommended to replace
the ink cartridge as soon as possible to avoid running out of ink during printing.
• When using white ink for this device, SS21W-2 (SPC-0504W-2) must be used. Do not use other than
this.
• While [NEAR END] is displayed, the setting for cleaning during printing is disabled. ( P.3-26)
