App - 46
APPENDICES
(2) Instructions added after function version B
With function version B, the following instructions can be used in addition to the
instructions in (1).
Refer to Section 2.2 for the function version.
Classification Function Instruction Symbol
AJ71ID -R4 control
instruction
Comparison read from ID data carrier IDCRD1, IDCRD2
Comparison write to ID data carrier IDCWD1, IDCWD2
Continuous comparison read from ID data
carrier
IDSRD1, IDSRD2
Continuous comparison write to ID data carrier IDSWD1, IDSWD2
Continuous high-speed read from ID data
carrier
IDFRD1, IDFRD2
Continuous high-speed write to ID data carrier IDFWD1, IDFWD2
CC-Link control instruction
Read from the buffer memory of the intelligent
device station
RIRD
Write to the buffer memory of the intelligent
device station
RIWT
Write to the buffer memory of the intelligent
device station(with handshake)
RISEND
Read from the buffer memory of the intelligent
device station (with handshake)
RIRCV
Read from master station buffer memory for
automatic update
RIFR
Write to master station buffer memory for
automatic update
RITO
Intelligent device station communication CCL, CCLEND
Intelligent device station communication status
read
SPCBUSY
Intelligent device station communication
processing interrupt
SPCCLR
Remote register (RWr) read RDGET
Remote register (RWw) write RDPUT
Remote register (RWr) monitor RDMON
