NAiS FP1 User Manual

3. Intelligent Units
4. Link Units
FP1 Transmitter
Master Unit
FP1 I/O Link Unit
C-NET Adapter
C-NET Adapter S1 type
(for FP1 Control Unit only)
Operating voltage
24 V DC
100 V to
240 V AC
24 V DC
100 V to
240 V AC
24 V DC
100 V to
240 V AC
Part number
AFP1752
AFP1756
AFP1732
AFP1736
AFP8532
AFP8536
AFP15401
Type Specification
FP1 Transmitter Master Unit enables the FP1 to
exchange I/O information with slave stations at a
remote site using a twisted pair cable. By connecting
with another FP1 Transmitter Master Unit or with an
FP3 Transmitter Master Unit, you can exchange I/O
information with another FP1. Communication
medium (RS485 port): Twisted pair cable up to 32
inputs and 32 outputs can be controlled per unit.
The FP1 I/O Link Unit is the interface unit for
exchanging I/O information between an FP3/FP5
and an FP1.
When the FP1 is connected to the FP3/FP5 Remote
I/O System via the FP1 I/O Link Unit, you can
exchange I/O information serially, using a
2-conductor cable.
RS485 ↔ RS422/RS232C signal converter
Used for communication between the Programmable
Controller and your computer.
Communication medium (RS485 port): 2-conductor
cable or twisted pair cable
RS485 ↔ RS422 signal converter for FP1 Control
Unit.
Used for communication between the C-NET
Adapter and FP1 Control Unit.
FP1 A/D Converter Unit
FP1 D/A Converter Unit
• Analog input points:
• Analog input range:
• Digital output range:
• Analog output points:
• Analog output range:
• Digital input range:
24 V DC
100 V to
240 V AC
24 V DC
100 V to
240 V AC
AFP1402
AFP1406
AFP1412
AFP1416
4 channels/unit
0 to 5 V, 0 to 10 V,
0 to 20 mA
K0 to K1000
2 channels/unit
0 to 5 V, 0 to 10 V,
0 to 20 mA
K0 to K1000
Type Specification Operating voltage Part number
11
1-2. Table of FP1 Units
