4. NPST-GR Settings
When modem communication is performed between an FP1 and a personal computer installed with NPST-GR
Software, you need to set the NPST-GR Software as follows.
1 Select “NPST CONFIGURATION” from the “NPST MENU” and then select
“
1. NPST CONFIGURATION” to
open the <SCREEN 1> window in the OFFLINE mode.
2 Set the parameters in the <SCREEN 1> window as follows:
PLC TYPE ........................select the one you want to communicate with.
COM PORT ......................select 1 or 2 of your personal computer
TRANS RATE (bps).........set to 2400 bps
DATE LENGTH............... select 8 or 7 bits according to that which you specified for the PLC.
3 Set the parameters in the <SCREEN 2> window as follows:
By pressing the F6 key, you can open the <SCREEN 2> window.
C-NET USE ......................select YES or NO
STATION UNIT NO........set the station number (UNIT NO.) of the target programmable controller.
SAVE INIT LOAD SCRN 1 MODEM INST RELAY FUN 1
OFFLINE NPST CONFG <SCREEN 2>
ADDR 0 SIZE 0 NOP :
1 2 3 4 5 6 7 8 9 10
[ NPST CONFIGURATION ]
COMMENT LENGTH
I/O COMMENT [ 12 ] char ( 12-40 ) ENTER EVEN VALUE
REMARK [ 20 ] char ( 12-40 ) ENTER EVEN VALUE
NUMBER OF COMMENT I/O CMT 14034 CURRENT REG: 0
REGISTER[ 1001 ] word (50 word or more)
REMARK [ 700 ] (22 byte/remark)
REST : 33543 byte
MENU TYPE [ MENU 1 / MENU 2 ]
DISPLAY LANGUAGE [ ENGLISH ]([ENTER]:OPENS WINDOW)
C-NET USE [ YES / NO ]
STATION UNIT NO.[ 1 ] ( 0 - 64 ) UNIT NO=0...HOME
MEWNET-H USE [ NONE / USE (RS422) / USE (RS232C)]
SAVE INIT LOAD SCRN 2 MODEM INST RELAY FUN 1
OFFLINE NPST CONFG <SCREEN 1>
ADDR 0 SIZE 0 NOP :
1 2 3 4 5 6 7 8 9 10
[ NPST CONFIGURATION ]
SCREEN MODE [ MONO / COLOR ]
PLC TYPE [ FP3/FP-C 16k ]([ENTER]:OPENS SELECTION WINDOW)
COM PORT [ 1 2 ]
TRANS RATE(bps) [ 19200 / 9600 / 4800 / 2400 / 1200 / 600 / 300 ]
DATA LENGTH [ 8 / 7 ] bit
LOGGED DRICVE/DIRECTORY
DRIVE [ A B C D E ]
DIRECTORY
[ ]
NOTE DISPLAY [ ON / OFF ]
PROGRAMMING MODE [LADDER/ B.LADDER / BOOLN ]
NOTE : SPECIFY TRANS RATE TO 9600 or 19200bps TO CONNECT WITH PLC DIRECTLY
OFFLINE NPST MENU BOOLEAN
ADDR 0 SIZE 0 NOP :
1 2 3 4 5 6 7 8 9 10 EXIT
[ NPST MENU ] (Ver. 3.14)
EDIT A PROGRAM
COMMENTS
SEARCH [ NPST CONFIGURATION ]
MONITOR
RELAYS/REGISTERS 1.NPST CONFIGURATION
CHECK A PROGRAM
NPST CONFIGURATION
PLC CONFIGURATION
PROGRAM MANAGER
IC CARD PROGRAM MANAGER
EXIT NPST-GR
PLC TYPE [ FP3/FP-C 16k ]
PLC MODE [ OFFLINE ]
PROGRAM NAME [ ]
USE/MAX (STEP) [ 0/ 7679]
**= NOT AVAILABLE
252
8-8. FP1 Modem Communication
